Internal non threaded terminal connection, firmly connected, suitable for different specifications of wires, quick assembly ;

The XSY16A plug-in light control base is assembled with XSY-18 waterproof connector threads for easy application. After combined use, it can achieve IP66 waterproof effect ;

Adopting silicone material sealing gasket and sealing tube, nylon material tooth tube and nut tight fitting, effectively achieving dust-proof and waterproof effect;

Wiring specifications: 18AWG/20AWG/22AWG, single hard wire/multiple hard wires can be directly inserted after opening for application, and multiple flexible wires can be dipped in tin for application ;

XSY-18 waterproof connector is suitable for wire diameters of Ø 5-10mm, with a total stripping length of 25-30mm for the outer layer and 8-10mm for the inner layer of the core wire ;
